17DOF Humanoids Walking Robot (غير مربوط)

Robots height about 40 cm (standing leg is the bending state), the width is 23 cm, with 17 degrees of freedom. Head 1 degrees of freedom, arm four degrees of freedom, shoulder two degrees of freedom, the crotch of two degrees of freedom, the legs six degrees of freedom, the foot 2 degrees of freedom.

Many improvements are made on the the robot’s leg structure, makes the leg structure more reasonable, so that robots can do more.

Features:
– Arches punching, corner cutting
– Cost-effective and easy-to-use
– For hobbyists, robot competition, kids
– Humanoid robot
– Color: Black
– Size: 40cm(H) x 23cm(W)

The ​MG996R 180 degree Digital Servo Parameters:
– Dimension : 40.8mm x 20mm x 38mm
– Weight : 55g
– Connector Wire: 11.81″  (300mm)
– Operating Speed: 0.17sec / 60  degrees (4.8V)
– Operating Speed: 0.13sec / 60  degrees (6.0V)
– Operation Voltage : 4.8 – 7.2Volts
– Torque:13KG.CM(4.8); 15KG.CM(6.0V)
– Gear Type: All Metal Gears

Containing the 17DOF:
– 1DOF of the head
– 4DOF of the arm
– 2DOF of the shoulder
– 2DOF of the hip
– 6DOF of the legs
– 2DOF of the feet

Package Includes:
17 x High torque servo
17 x Metal Steering wheel
16 x Multifunctional Bracket
4 x Long U-shaped Bracket
7 x Short U-shaped Bracket
4 x Tilt U-shaped Bracket
4 x L-shaped support
1 x U-shaped beam
4 x One-word bracket
2 x Big Foot plate
14 x Cupped Bearing
1 x A full set of screws and nuts
