1000W 20A ZVS Induction Heating Board Flyback Drive Heater

Features:

• 12-48V low voltage power supply
• Rated current: 20A
• Rated power: 1000W, the bigger voltage, the higher power.

Test Results:

• We tested when it works 53V power supply, current can reach 30A. It can be used for DIY players to make
• small parts quenching, annealing and other heat treatment, heating fast, very convenient.
• 24V input and no-load current is about 3A
• 48V input and no-load current is about 6A

Important Notes:

• The higher voltage, the higher current when heating the same things, the effect is better, but at the same time heating is also higher, therefore the choice of input voltage is based on your need. Such as heating under 1cm square small objects, use the 24v voltage.
• The buyer needs self-provided power and cooling device
• When made with switch power supply, because of the high power generally has function of soft start, namely just powered on the output voltage is slowly rising, while if before the voltage up to 12v connected induction heating circuit, will not work and burn MOS tube. So, voltage reaches more than 12 v connected induction heating circuit.
• The volume of heated objects cannot be more than 1/10 of the heating coil internal volume (that is, the heating cylinder diameter more than 1/3 heating coil diameter), otherwise it may because of overload and burned circuit or the power supply. Although this circuit can tolerate 30A input current, but the insurance for the purpose of work not more than 20A.
• This circuit can do induction heating, or replace copper tube with high frequency transformer, it will be a powerful inverter

Cooling tips:

• To increase the heat sink using a customized substrate as thick as 8.5mm!
• Cooling capacity is very powerful.
• Using the M4 pillars, fever smaller, more efficient.

Package Includes:
1 x Induction Heating Board 1000W
