Bluetooth OBDII Car Diagnostic Interface

Features:
– The newly developed wireless scan tool.
– It supports almost OBD-II protocols.
– Bluetooth connection, no Batteries, Cables, or Switches.
– Wireless (Bluetooth) 5~10 meter
– Retrieve Fault Codes (DTCs) and clear Check Engine lights.
– Can also be used with a PC with a Bluetooth Card.
– Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
– Clear trouble codes and turn off the MIL (“Check Engine” light)
– Set the maximum number of responses to obtain
– Remove spaces from ECU responses (to speed data transmission)
– Store a unique identifier in EEPROM
– Set the CAN mask and filter with one command
– Easily switch between variable and fixed CAN message lengths
– Send CAN remote frames (RTRs)
– ELM327 V1.5 MCU

Display current sensor data, including:
Engine RPM, Calculated Load Value, Coolant Temperature, Fuel System Status, Vehicle Speed, Short Term Fuel Trim, Long Term Fuel Trim, Intake Manifold Pressure, Timing Advance, Intake Air Temperature, Air Flow Rate, Absolute Throttle Position, Oxygen sensor voltages/associated short term fuel trims, Fuel System status, Fuel Pressure, and many others…

Multi-Protocol Support:

1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2(5 baud init, 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
5. ISO14230-4 KWP (fast init, 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID, 500 Kbaud)
7. ISO15765-4 CAN (29bit ID, 500 Kbaud)
8. ISO15765-4 CAN (11bit ID, 250 Kbaud)
9. ISO15765-4 CAN (29bit ID, 250 Kbaud)
10. SAE J1939 CAN (29bit ID, 250*Kbaud)
11. USER1 CAN (11*bit ID, 125*Kbaud)
12. USER2 CAN (11*bit ID, 50*kbaud)

*default settings (user adjustable)

Important:
– Works on all OBD2 Vehicles (1996 onwards in USA) and EOBD vehicles (Petrol cars from 2001 and diesel cars from 2003/2004 in Europe)
– For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant, Alfa Romeo/ Audi/ Bentley/ BMW/ Cadillac/ Chevrolet/ Chrysler/ Citroen/ Daewoo/ Fiat/ Ford/ GM/ Honda/ Hyundai/ Isuzu/ Jaguar/ Jeep/ Kia/ Landover/ Lexus/ Mazda/ Mercury/ Mini/ Nissan/ Mitsubishi/ Opel/ Peugeot/ Renault/ Rover/ Saab/ Seat/ Skoda/ Toyota/ Vauxhall/ Volvo/ VW
– Bluetooth pair code: 1234

Mobile Application
https://play.google.com/store/apps/details?id=org.prowl.torquefree

Packing Includes:
1 x V1.5 OBDII Bluetooth Diagnostic Interface
